Peguet 12mm (1/2") Stainless Steel Standard Maillon Rapide Quick Link
Peguet | SKU:
N-120-SS
$71.14
$83.69
Unit price
/
Unavailable
Peguet 12mm (1/2") Stainless Steel Standard Maillon Rapide Quick Link is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Payment
Payment
- Credit Cards: We accept major credit cards, including Visa, Mastercard, American Express, and Discover.
- Apple Pay & Google Pay: Simplify your checkout process using these digital wallets.
- Shop Pay: For faster checkouts and secure payment processing.
Shipping
Shipping
Ground, 2nd Day Air and Next Day Air available ! Same Day Shipping if your order is placed by 4pm Eastern
Returns
Returns
At Harbor Supply, we aim to ensure you’re completely satisfied with your purchase. If you need to return an item, you have 90 days from the date of delivery to initiate a return.
Eligibility for Returns:
To be eligible for a return:
- The item must be in its original condition—unused, unworn, with all tags still attached, and in its original packaging.
- You’ll need the receipt or proof of purchase.
Please note, returns must be authorized before sending any items back. Items returned without prior authorization will not be accepted.
Peguet 12mm (1/2") Stainless Steel Standard Maillon Rapide Qui...
$71.14
$83.69
Unit price
/
Unavailable
Description
Description
Product Description
Peguet 12mm (1/2") Stainless Standard Maillon Rapide Quick Link
The original oval shape was developed on the principle of a chain link fitted with manual nut opening. This shape reflects the spirit of Maillon Rapide quick links connectors.
Specifications:
Diameter: 12MM or 1/2"
HT: 104.5mm
HI: 80.5mm
A: 23.5mm
O: 15mm
E: 33mm
T: 15mm
Weight: 238g (0.5247 lbs)
Working Load: 2500kg (5511 lbs)
Breaking Load: 12500kg (27,558 lbs)
The original oval shape was developed on the principle of a chain link fitted with manual nut opening. This shape reflects the spirit of Maillon Rapide quick links connectors.
Specifications:
Diameter: 12MM or 1/2"
HT: 104.5mm
HI: 80.5mm
A: 23.5mm
O: 15mm
E: 33mm
T: 15mm
Weight: 238g (0.5247 lbs)
Working Load: 2500kg (5511 lbs)
Breaking Load: 12500kg (27,558 lbs)
Material:
Stainless Steel
Rod: Standard X2 Cr Ni, Mo 17-12-2 (1.4404), AISI 316L
Nut: Standard X2 Cr Ni
18/12 chrome-molybdenum steel with very low carbon content, protected from inter-granular corrosion. (Rod & Nut)
Fit in environments where 18.10 steels stand up corrosion, excepted those involving nitric acid. (Rod & Nut)
2/2,5 molybdenum content allowing its use in more applications than those complying with 18.10 steels, particularly with sulphuric acids and chlorides in marine environments. (Rod & Nut)
Tightening Torque:
ط F 2,5 3,0 3,5 4,0 5,0 6,0 7,0 8,0 9,0 10,0 12,0 14,0 16,0 18,0 20,0
Torque 0,15 0,30 0,60 0,70 0,80 1,20 2,50 3,00 4,50 7,00 9,00 12,00 18,00 30,00 40,00
Recommendation:
Keep to the working load limit WLL engraved in kg.
Visual check of complete nut screwing compulsory; no thread must be showing.
Maillon Rapide quick links are only to be loaded along the major axis.
Maillon Rapide quick links should be carefully checked at regular intervals. If you are in any doubt about the safety of a quick link after checking, replace it with a new one.
When fastened with a wrench up to the proper tightening torque, Maillon Rapide quick links are considered a permanent connector.
Maillon Rapide should always be fitted with parts made of same material.
When connected with chain, Maillon Rapide quick links should be of the same diameter.
Never connnect any Maillon Rapide quick links onto a lifting chain.
Stainless steel Maillon Rapide quick links may be used in salt water.
P.P.E. EN 362 & EN 12275 Standards: Maillon Rapide quick links must be accopagnied by user instructions when sold or used as a connector on P.P.E. (Personal Protective Equipment).
